Drafting and Design
2022 - Abu Dhabi, UEA
Modern one‑level with tall shed roofs, big windows, and a 160‑sq‑ft primary closet.
Table of contents
Overview
Solenne is a modern, single‑story residence defined by tall shed‑roof volumes, broad window groupings, and a calm, open core. A privacy‑oriented primary wing with a 160‑sq‑ft walk‑in closet anchors one side, while two guest bedrooms share a efficient bath on the other. Exposed beams and elevated ceilings bring scale, light, and quiet drama to everyday living.
Client Type
Solenne suits those seeking clean contemporary lines with warm, livable proportions. It favors clarity over clutter, delivering open flow for hosting, private retreat space, and straightforward construction detailing for a smooth permit path.
Project Scope
The Solenne project provides a complete, permit‑ready set for a slab‑on‑grade, one‑level home. The architectural program includes:
Approximately 1,850–1,890 sq ft, single story
Open living, kitchen, and dining with cabinet‑forward wall and window strategy
Primary suite with 160‑sq‑ft walk‑in closet and spa‑style bath
Two secondary bedrooms with a shared bathroom
Shed‑roof form supporting 10.5'–11' walls and ~12' ceilings with exposed beams
Coordinated door heights (8' interiors), exterior proportions, and large glazing
Slab and roof plans, and MEP intent sized to residential review
Challenges Addressed
Balancing expansive glazing with privacy and thermal clarity
Achieving tall, beam‑friendly ceilings within a simple shed‑roof structure
Right‑sizing storage and a non‑negotiable 160‑sq‑ft primary closet
Keeping circulation efficient while separating public and private zones
Goals Achieved
✔️ Light‑rich open core with disciplined cabinet and window placement
✔️ Private primary suite with generous closet and spa bath
✔️ Clear shed‑roof logic that supports tall ceilings and beam expression
✔️ Efficient secondary wing and guest bath for everyday practicality
✔️ Straightforward documentation tuned for permitting and build coordination


AutoCad
Solenne distills contemporary living into a bright, beam‑accented plan with a tall shed‑roof profile. An open central core, generous glazing, and a private primary suite with a 160‑sq‑ft closet balance daily ease and quiet luxury. With slab, roof, and MEP intent coordinated, the set is tuned for clear permitting, confident pricing, and a clean build start.
